WireGuard Easy

You have found the easiest way to install & manage WireGuard on any Linux host!

Features

• All-in-one: WireGuard + Web UI.
• Easy installation, simple to use.
• List, create, edit, delete, enable & disable clients.
• Show a client's QR code.
• Download a client's configuration file.
• Statistics for which clients are connected.
• Tx/Rx charts for each connected client.
• Gravatar support.
• Multi-user management with Redis database

Requirements

• A host with a kernel that supports WireGuard (all modern kernels).
• A host with Docker and docker-compose installed.

Installation

1. Run WireGuard Easy

To install & run wg-easy:

$ git clone https://github.com/Elemento-Modular-Cloud/wg-easy.git
$ cd wg-easy

💡 Here you want to edit the docker-compose.yml file.

💡 Replace YOUR_SERVER_IP with your WAN IP, or a Dynamic DNS hostname.

💡 If you enable USERS_PATH be sure to place your file inside ./src/.

💡 Your configuration files will be saved in ~/.wg-easy

$ docker-compose up

The Web UI will now be available on http://0.0.0.0:51821.

2. Sponsor

Are you enjoying this project? Buy him a beer! 🍻

Options

These options can be configured by setting environment variables inside docker-compose.yml.

Env	Default	Example	Description
WG_HOST	-	vpn.myserver.com	The public hostname of your VPN server.
USERS_PATH	-	/app/users.json	The path to a JSON file located under ./src/(users.json) made of users and passwords.
WG_DEVICE	eth0	ens6f0	Ethernet device the wireguard traffic should be forwarded through.
WG_PORT	51820	12345	The public UDP port of your VPN server. WireGuard will always listen on 51820 inside the Docker container.
WG_MTU	null	1420	The MTU the clients will use. Server uses default WG MTU.
WG_PERSISTENT_KEEPALIVE	0	25	Value in seconds to keep the "connection" open. If this value is 0, then connections won't be kept alive.
WG_DEFAULT_ADDRESS	10.8.0.x	10.6.0.x	Clients IP address range.
WG_DEFAULT_DNS	1.1.1.1	8.8.8.8, 8.8.4.4	DNS server clients will use.
WG_ALLOWED_IPS	0.0.0.0/0, ::/0	192.168.15.0/24, 10.0.1.0/24	Allowed IPs clients will use.
WG_PRE_UP	...	-	See config.js for the default value.
WG_POST_UP	...	iptables ...	See config.js for the default value.
WG_PRE_DOWN	...	-	See config.js for the default value.
WG_POST_DOWN	...	iptables ...	See config.js for the default value.

If you change WG_PORT, make sure to also change the exposed port.

Common Use Cases

• Using WireGuard-Easy with Pi-Hole
• Using WireGuard-Easy with nginx/SSL
